Monoblock Pumpset



Features

Accredited with ISO certificate
Most of the models with ISI mark
Available with Stainless Steel & Bronze MOC
Optimum head & discharge with lower power consumption
Withstands wide voltage fluctuations

Application

Water supply system
Pressure boosting
Cooling towers
Flow / Drip / Sprinkler irrigation

Range
Phase Single Phase Three Phase
Head in Mtr. 6 to 32 8 to 70
Discharge in LPM 25 to 1350 115 to 23384010
HP 0.50 to 3.00 3.00 to 20.00
Stage 1"x1" to 4"x4" 2"x1.5" to 6"x6"

Water supply system

Cooling towers

Pressure boosting

Flow / Drip / Sprinkler irrigation


Standard Material of Constructions (MOC)
Sr. No. Pumpset Components Material
1. Motor Frame C.I. Gr. FG200 IS 210 / Aluminum
2. Pump Casing ( Volute ) Cast Iron (Stainless or Gun Metal on Specific Demand)
3. Suction / Delivery Flange Cast Iron (Stainless or Gun Metal on Specific Demand)
4. Impeller Cast Iron (Stainless or Gun Metal on Specific Demand)
5. Shaft EN-8 Mild Steel (AISI – SS 410 on Specific Demand)
6. Sealing Gland Pack / Mechanical Seal (Carbon – Ceramic)
7. Cooling Fan P.V.C. Nylon
8. Cooling Fan Cover Mild Steel (M.S.)
9. Lock Nut to Impeller Nylock Nut
