Horizontal Mono Submersible Pumpset



Features

Wet type, water cooled rewindable motors
Withstands wide voltage fluctuations
Ideal for fluctuating water level wells
No foot valve, no gland, no priming
Easy installation

Application

Building / bungalow water supply
Cooling towers
Garden, Fountains & Shrimp farm
Flow / Drip / Sprinkler irrigation

Range
Phase Single Phase Three Phase
Head in Mtr. 5 to 32.5 8 to 70
Discharge in LPM 45 to 900 130 to 3250
HP 0.50 to 3.00 2.00 to 30.00
Stage 1"x1" to 3"x3" 2"x1.5 to 5"x5"

Building / bungalow water supply

Cooling towers

Garden, Fountains & Shrimp farm

Flow / Drip / Sprinkler irrigation


Standard Material of Constructions (MOC)
Sr. No. Pumpset Components Material
1. Motor body M.S. + AISI SS 410 Shell Cover / Cast Iron
2. Impeller Cast Iron (SS or Bronze on Demand)
3. Shaft EN 8 Mild Steel (AISI – SS 410 on Specific Demand)
4. Casing C.I. Gr. FG200 IS 210
5. Thurst Bearing Ghrome Steel vs Carbon
6. Bearing Bush LTB – 5
7. Shaft Sleeve AISI – SS 410
8. Winding PVC / Polyster insulated , Water Cooled
