Submersible Cables



Features

High annealed conductivity & bunched flexible electrolytic bright bare
copper conductors ensuring long life
High grade flexible PVC insulation and PVC Sheath
Good withstanding capacity to high voltage and current
Extends the life of electrical equipments
Excellent Mechanical & Electrical Equipments
Excellent Mechanical & Electrical Properties

Application

Provides power to all types of internal and external moveable and fixed pumping installations
Submersible cables are used to supply power to submersible pumps for –
Irrigation
Drinking Water
Industries
Fountains
Fire Fighting

Range
Available Size in Sq.MM 1, 1.5, 2.5, 4, 6, 10, 16, 25, 35, 50, 70, & 95
Available Types Flat / Round Cable, 3 / 4 Core and PVC Sheath

Irrigation

Fire Fighting

Fountains


Specifications
Voltage Rating 1100 Volts
Temperature Range From -15 C to + 70 C
Insulation Material Dielectric grade PVC Compound imper vious to water, oils grease etc.
Sheath Material High abrasion resistant tough & flexible PVC Compound
Sheath Colour Black / Blue
Core Colour 3 Core – Red, Yellow & Blue or Black, Light Blue and Brown
4 Core – Red, Yellow, Blue & Green / Black or Black, Light Blue, Brown, Yellow with Green Line or Green with Yellow Line
