6” Submersible Pumpset-Water Filled
Features
Wet type, water cooled rewindable motors
Withstands wide voltage fluctuations
Most of the models have ISI marks
Available with stainless steel & bronze MOC
Long life due to sturdy construction
Application
Field Irrigation
Private / Public water supply
Flow / Drip / Sprinkler irrigation
High rise building & Fire fighter
Pvt / Public water supply & Firefighting
| Range | ||
|---|---|---|
| Suitable For Borewell Size | 6" & Above | |
| Phase | Three Phase | |
| Head in Mtr. | 7 to 271 | |
| Discharge in LPM | 40 to 1250 | |
| HP | 3 to 30 | |
| Stage | 2 to 30 | |
Field Irrigation
Private / Public water supply
Flow / Drip / Sprinkler irrigation
High rise building & Fire fighter
Pvt / Public water supply & Firefighting
| STANDARD MATERIAL OF CONSTRUCTIONS (MOC) | ||
|---|---|---|
| Sr. No. | Motor Parts | Material |
| 1. | Rotor Shaft | EN9 / AISI – SS 410 |
| 2. | Stator Body / Casing | Stainless Steel / AISI – SS 304 |
| 3. | Housing | C.I. Gr. FG200 IS 210 |
| 4. | Base Cover | C.I. Gr. FG200 IS 210 |
| 5. | Thrust Bearing Segment | AISI 420 hardened |
| 6. | Thrust Bearing Liner | Carbon / Polymer |
| 7. | Bearing Diaphragm | Nitrile Rubber |
| 8. | Bearing Bush | Leaded Tin Bronze |
| Sr. No. | Pump Parts | Material |
| 1. | Casing | C.I. Gr. FG200 IS 210 |
| 2. | NRV Body | C.I. Gr. FG200 IS 210 |
| 3. | Suction Casing | C.I. Gr. FG200 IS 210 |
| 4. | Pump Shaft | AISI – SS 410 |
| 5. | Pump Sleeve | Stainless Steel / AISI – SS 410 |
| 6. | Impeller | Bronze / Stainless Steel / AISI – SS 304, SS 410 |
| 7. | Casing Wearing Ring | Nitrile Rubber / Leaded Tin Bronze |
