4” Submersible Pumpset-Water Filled



Features

Wet type, water cooled rewindable motors
High operating efficirncy & low power bills
Withstands wide voltage fluctuations
Most of the models have ISI marks
Light weight & Noiseless operation

Application

Private / Public water supply
Flow / Drip / Sprinkler irrigation
Small discharge high pressure water supply
Fire fighting, Bungalows & Apartments

Range
Suitable For Borewell Size 4" & Above 4" & Above
Phase Single Phase Three Phase
Head in Mtr. 4 to 208 4 to 240
Discharge in LPM 16 to 360 17 to 360
HP 0.5 to 3 0.75 to 7.5
Stage 5 to 40 5 to 50

Private / Public water supply

Flow / Drip / Sprinkler irrigation

Small discharge high pressure water supply

Fire fighting, Bungalows & Apartments


Standard Material of Constructions (MOC)
Sr. No. Motor Parts Material
1. Rotor Shaft AISI – SS 410
2. Stator Body / Casing Stainless Steel
3. Housing C.I. Gr. FG200 IS 210
4. Base Cover C.I. Gr. FG200 IS 210
5. Thrust Bearing Segment AISI – SS 420
6. Thrust Bearing Liner Carbon / Polymer
7. Bearing Diaphragm Nitrile Rubber
8. Bearing Bush Leaded Tin Bronze
Sr. No. Pump Parts Material
1. Casing Noryl
2. NRV Body C.I. Gr. FG200 IS 210
3. Suction Casing C.I. Gr. FG200 IS 210
4. Pump Shaft AISI – SS 410
5. Pump Sleeve AISI – SS 410
6. Impeller Noryl
