4” Submersible Pumpset-Oil Filled



Features

Oil cooled, rewindable motors.
Withstand wide voltage fluctuation & Better low voltage starting.
Light weight & Noiseless operation
Maintenance free operation because of oil lubricated ball bearing pump
Starting capacitor not required.

Application

Water supply system
Flow / Drip / sprinkler irrigation
Fire Fighting
Civil & Industrial
Bungalows & Apartments

Range
Suitable For Borewell Size 4" & Above 4" & Above
Phase Single Phase Three Phase
Head in Mtr. 3 to 195 3 to 210
Discharge in LPM 13 to 375 17 to 375
HP 0.5 to 3 0.75 to 5
Stage 4 to 44 5 to 45

Bungalows & Apartments

Civil & Industrial

Fire Fighting

Flow / Drip / sprinkler irrigation

Water supply system



STANDARD MATERIAL OF CONSTRUCTIONS (MOC)
Sr. No. Motor Parts Material
1. Rotor Shaft AISI – SS 410 / AISI – SS 431
2. Motor Body / Stator Stainless Steel / Vaccum Impregnated with Class ‘F’ insulation
3. Housing C.I. Gr. FG200 IS 210
4. Base Cover C.I. Gr. FG200 IS 210
5. Bearing Angular Contact Bearing / Ball Bearing
6. Seal Mechanical Seal (Carbon - Ceramic)
7. Breather Diaphragm Nitrile Rubber
Sr. No. Pump Parts Material
1. Pump Shell Stainless Steel
2. NRV Body C.I. Gr. FG200 IS 210
3. Suction Casing C.I. Gr. FG200 IS 210
4. Pump Shaft AISI – SS 410
5. Pump Sleeve AISI – SS 410
6. Impeller / Bowl Noryl
