10” Submersible Pumpset-Water Filled



Features

Wet type, water cooled rewindable motors
Withstands wide voltage fluctuations
Most of the models have ISI marks
Available with stainless steel & bronze MOC
Long life due to sturdy construction

Application

Field Irrigation
Private / Public water supply
Flow / Drip / Sprinkler irrigation
High rise building & Fire fighter
Pvt / Public water supply & Firefighting

Range
Suitable For Borewell Size 10" & Above
Phase Three Phase
Head in Mtr. 4 to 264
Discharge in LPM 50 to 4000
HP 15 to 125
Stage 1 to 13

Small discharge high pressure water supply

Private / Public water supply

High rise building & Fire fighter

Flow / Drip / Sprinkler irrigation


Standard Material of Constructions (MOC)
Sr. No. Motor Parts Material
1. Rotor Shaft EN9 / AISI – SS 410
2. Stator Body / Casing Stainless Steel / AISI – SS 304
3. Housing C.I. Gr. FG200 IS 210
4. Base Cover C.I. Gr. FG200 IS 210
5. Thrust Bearing Segment AISI 420 hardened
6. Thrust Bearing Liner Carbon / Polymer
7. Bearing Diaphragm Nitrile Rubber
8. Bearing Bush Leaded Tin Bronze
Sr. No. Pump Parts Material
1. Casing C.I. Gr. FG200 IS 210
2. NRV Body C.I. Gr. FG200 IS 210
3. Suction Casing C.I. Gr. FG200 IS 210
4. Pump Shaft AISI – SS 410
5. Pump Sleeve Stainless Steel / AISI – SS 410
6. Impeller Bronze / Stainless Steel / AISI – SS 304, SS 410
7. Casing Wearing Ring Nitrile Rubber / Leaded Tin Bronze
